BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable

China Henan Duxin Science Technology Co.,Ltd. certification
I'm Online Chat Now

BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable

BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable
BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable

Large Image :  BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable

Product Details:
Place of Origin: China
Brand Name: Xinguang lithium battery
Certification: CE,MSDS,ROHS,un38.3
Model Number: 48v 80Ah
Payment & Shipping Terms:
Minimum Order Quantity: 1 PACK
Price: Negotiable
Packaging Details: Standard export carton, wooden case, pallet etc.
Delivery Time: 5-15 days for samples, 25-35 days for bulk order
Payment Terms: L/C, T/T, paypal,, Western Union
Supply Ability: 50,000 PCS
Detailed Product Description
Type: 48v 80Ah Lithium Iron Power Battery Product Name: Power Battery Packs
Oem/odm: Accept Battery Capacity: 80Ah
Size: Customed Warranty: 3 Years
Certification: Ce, MSDS, UN38.3, ROHS Cycle Life: >3000
High Light:

48v 80Ah Power Battery Packs


BMS Lithium Power Battery Packs


BMS 48v 80ah lithium battery

BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable


48v 80Ah Lithium Iron Power Battery Instruction


The 48v 80Ah lithium battery is supplied with a LiFePO4 Battery Management System (BMS)that can monitor and optimized each single prismatic cell during battery charge & discharge, to prevent the 48V 80Ah battery pack from overcharge, over discharge, short circuit, over current. The BMS helps to ensure safe and accurate running of the lithium battery pack. Except BMS, the battery has dual protection of Air switch in case of short circuit. The LED indicators on battery case indicate the battery capacity, running status and the battery also has alarm functions.

48v 80Ah Lithium Iron Power Battery Specifications


No. Item General Parameter Remark
1.1 Description PAC technology 48V Lithium iron phosphate battery 80Ah for solar energy storage
1.2 Cell Type prismatic LiFePO4 cell 15S2P
1.3 Typical Capacity 80Ah
1.4 Typical Voltage 48V
1.5 End of Charge Voltage 54V
1.6 Charge Current 0.2C
1.7 Charging time 5-6 Hours
1.8 Over-Charge Voltage Protection cell 3.6V
1.9 Max continuous charge current 40A
2.0 Maximum Continuous Discharging Current 80A
2.1 Over-discharge Voltage Protection cell 2.5V
2.2 Over-Current Discharge Protection 300A
2.3 Protection functions overcharge, overdischarge, over current, short circuit, over temperature, over load
2.4 Dual protection Air switch
2.5 Weight about 46kgs
2.6 Operation Temperature Range Charge 0~60 C, Discharge -20~60 C
2.7 Storage Temperature & Humidity Range Less than 1 month:-20℃~45℃,45%RH~75%RH
Less than 3 months:-10℃~35℃,45%RH~75%RH

Recommended storage environment:



Long time storage:

If the battery need be stored for a long time, the voltage should be at 50%SOC, and stored in the condition as storage proposal. It needs at least one charge & discharge cycle every six months.



Advantage of PAC Technology company:
We offer quick response to your inquiry and reliable battery quality based on your requirements.
We provide not only professional solutions for your product, but also full technical support after sales.
So if you have any inquiries, please feel free to contact us.



Safety Test

No fire, no explosion

Charing to 3.7v and do nail penetration test, there is no fire, no explosion, no any other obvious changes.


Nail Penetration Test and Overcharge Test

After testing, no fire and no explosion, that is definitely approved than our lithium batteries deserve you.


Features of 48V 80Ah PAC battery:

  • Built-in smart BMS with alarm function
  • High working voltage for single battery cells
  • Pollution-free
  • Long cycle life
  • With dual protecion
  • Factory price & High quality
  • Good consistency, low self discharge



Applications for LiFePO4 Battery 24V:

· Energy Storage Systems (ESS)

· Hybrid Grid back-up

· Remote area power systems

· Communications systems

· Electric vehicles

· Marine environments

· Military & Aviation

· Industrial Machinery

· Uninterruptible Power Supplies

· CCTV & Data Transfer

BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable 0

Advantage of 24V  15Ah LiFePO4 polymer battery With Built-in BMS, deep cycle battery pack, Comparing to Lead Acid Battery
Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A ‘drop in’ replacement for lead acid batteries.
Higher Power: Delivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity.
Wider Temperature Range: -20 C~60 C.
Superior Safety: Lithium Iron Phosphate chemistry eliminates
the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Increased Flexibility: Modular design enables deployment of up to four batteries in series and up to ten batteries in parallel.


Storage Conditions

◆For long time storage ,the battery should be charged to Approx 60% SOC ,its corresponding voltage should be 1.05times of nominal voltage(24V,36V,60Vor72V),usually it's voltage in shipment .The battery should be kept in storage in dry and ventilated place.

◆ The battery pack and charger should be stored in clean, dry and ventilated place, avoid contacting with corrosive materials and be away from fire and heat.



Our service


1. Customized service: OEM or ODM is OK.

2. Very fast delivery: ship within 3 days after receive payment.

3. Professional sales team: reply within 12 hours.

4. Strong R&D for mew product

5. Other special services, contact us you can feel


Standard charge Characteristics of LiFePO4 battery Pack
The "Standard Charge" means charging with constant current 0.2C to3.65V, then charging with constant voltage 3.65V to 0.01C under 20±5℃, charging time will not more than 8h.) (Use Lithium-ion battery charger, which with an accuracy ±0.05V.)


Battery Pack Delivery

• By Air Door to Door Service

• By Sea Door to Door Service

• By Express: EMS, TNT, UPS, FedEx

BMS 48v 80Ah Lithium Iron Power Battery Packs Rechargeable 1
